Kafka Logging Guide:
Advanced Concepts

Arfan Sharif - December 23, 2022

In part one of this two-part series on Kafka logging, we reviewed Kafka’s architecture and how it manages logs using named partitions inside topics. We also looked at some common commands to create and manipulate the topics using the console APIs.

In addition, we touched on how the append-only nature of Kafka logs can quickly result in high disk consumption. This can cause various issues, including slower data access or the inability to store larger messages. To address this, Kafka provides log retention policies, allowing you to store data in queues as purposefully as possible. You can also employ different compaction techniques with Kafka.

In part two, we’ll discuss these advanced compaction techniques and how to implement them within your Kafka cluster. We’ll also learn how to perform basic read and write operations to observe the compaction behavior.

What Is Kafka Log Compaction?

Compaction ensures that the latest and most relevant data exists. It eliminates data that is either redundant or no longer useful, thereby reducing disk utilization. Compaction simplifies traversing and backing up data while maintaining data integrity and consistency across your servers.

You can achieve compaction through different techniques, including:

  • Compressing and then deleting the data
  • Removing older records after they’ve passed a specified time threshold

Log compaction is a mechanism that allows robust control at the record level as well as at the system level. By using log compaction, you can decide which events to store in logs and for how long. You can also choose what data is not compacted at all.

Retention Based on Time or Size

A common approach to compaction is to use time- or size-based retention policies, either at the server level or the topic level.

Time-Based Retention Policy

Time-based compaction in Kafka is one of the basic techniques designed for a simpler and easier cleaning process of all cluster sizes. You can enable time-based retention by configuring the following properties:

  • log.retention.hours
  • log.retention.minutes
  • log.retention.ms

The default value for retention is 168 hours (seven days). For the above three properties, precedence is given to the smallest unit, meaning log.retention.ms takes the highest precedence. Setting a retention policy to a larger value will cause events to pile up inside the brokers. A smaller value might lead to data loss, as few consumers are running during the compaction period. Therefore, the correct value has to be determined according to the application and the user’s need to keep data relevant and available.

Consider the example below, in which we use the log.retention.ms property to set a retention policy of 600 milliseconds.

How to use log retention property to set retention policy of 600 milliseconds

Messages in Kafka will have a time to live (TTL) of 600 milliseconds, after which they are marked for deletion.

Size-Based Retention Policy

As an alternative, you can use size-based retention, compacting logs by configuring a size limit. For this, you would set the log.retention.bytes property to a value that best suits your application. By default, the threshold is set to -1, effectively disabling size limiting on the partitioned topic.

In the example below, the configured size threshold is 800 MB. The total size of the partitioned topic is kept at less than 800 MB.

configured size threshold of 800 MB and total size of the partitioned topic is kept at less than 800 MB.

Time with Size-Based Retention Policy

Both retention policies are powerful on their own, but you can combine these two policies in the Kafka nodes to further fine-tune the compaction process. The compaction process triggers separately for each configuration, maintaining highly compacted topics in the Kafka cluster.

Limitations of Server Level Retention Policies

As you can see, applying compaction policies on the server alleviates disk congestion issues and provides comprehensive control over the data. However, only applying retention policies at the server level won’t handle streams of data efficiently. For this, Kafka provides an enhanced compaction mechanism, targeting a single record in each topic by managing keys and offsets intelligently.

Kafka Log Compaction

Another technique for conserving disk space — specifically referred to as log compaction in Kafka — is a mechanism to maintain the last known value of each key inside every partition. Kafka’s documentation describes the technique this way:

Log compaction is a mechanism to give finer-grained per-record retention rather than the coarser-grained time-based retention. The idea is to selectively remove records where we have a more recent update with the same primary key. This way, the log is guaranteed to have at least the last state for each key.

The mechanics behind Kafka’s log compaction algorithm and process are beyond the scope of this article, but a detailed description can be found here.

How To Manipulate a Compacted Topic

Creating a Compacted Topic

To create a compacted topic, you need to call the console topic API and set the cleanup.policy property to compact, along with a reasonable number for retention. You can find the console APIs inside the Kafka bin directory on the Kafka server.

:~$ sh kafka-topics.sh --create --topic ls-compact-topic --partitions 3 --replication-factor 2 --bootstrap-server localhost:9065 --config “cleanup.policy=compact” --config “delete.retention.ms=150”

For the above command, once the ls-compact-topic topic reaches a threshold to indicate it needs to be compacted (this is called the “dirty ratio” and defaults to 50%), all the records older than 150 milliseconds are marked for compaction.

Publishing to the Compacted Topic

The following command publishes comma-separated key values to the ls-compact-topic using the console producer API.

:~$ sh kafka-console-producer.sh --topic ls-topic --bootstrap-server localhost:9065 --property parse.key=true --property key.separator=,

:~$ key1,ls1
:~$ key2,ls2
:~$ key1,ls4
:~$ key4,ls6
:~$ key3,ls3
:~$ key3,ls5

Consume the Compacted Topic

The following command consumes the ls-compact-topic and prints the key-value pairs, using the console consumer API.

:~$ sh kafka-console-consumer.sh --topic ls-topic --bootstrap-server localhost:9065 --property print.key=true --property key.separator=, --from-beginning

Assuming the compaction process has been completed on all segments, the above command would yield the below result:

key1,ls4
key2,ls2
key4,ls6
key3,ls5

Creating Retention Policies on a Topic

In this section, we’ll expand further regarding the impact of compacted policies on the logs.

Applying Server-Level Retention Policies in a Kafka Cluster

To update the retention configuration on the Kafka server, navigate to the config folder inside the Kafka directory and edit server.property file. Set the following configuration:

log.retention.bytes=800000000

This retains messages in all topics such that topics can reach a size of 800 MB.

Creating and Inspecting a Compacted Topic

Let’s assume we have created a compacted topic called ls-super-topic using the topic console API command, and we have set the log retention policies for this topic to 120 milliseconds and 800 MB.

Now, we can use the --describe flag command to view the retention property.

:~$ sh kafka-topics.sh --describe --topic ls-super-topic --bootstrap-server localhost:9065

Notice the topic has both time and size retention policies assigned to it.

retention.ms=120
retention.bytes=800000000

Creating a Compacted Topic with a Size-Based Retention Policy

Next, let’s create a compacted topic called ls-size-topic without specifying any retention property in the command. By doing so, we allow the topic to inherit the server’s retention policy.

:~$ sh kafka-topics.sh --create --topic ls-size-topic --partitions 3 --replication-factor 2 --bootstrap-server localhost:9065 --config “cleanup.policy=compact”

Observing the Behavior of These Two Topics

Suppose you have published three records using the same key, simultaneously to both the topics, as shown in the illustration below. You might notice how drastically the outcome changes based on the different policies. The compaction process is triggered every 120 milliseconds on the ls-super-topic, but the cleaner process is called on ls-size-topic only when the total size exceeds 800 MB.



Observing behavior of compacted topics
